YourCee MH-Z19E CO2 Sensor | NDIR UART PWM Gas Module

YourCee MH-Z19E CO2 Sensor - NDIR Carbon Dioxide Module with UART and PWM Output

The YourCee MH-Z19E is an NDIR carbon dioxide sensor module for indoor air-quality monitoring, HVAC experiments, smart-home ventilation, school air monitoring, and CO2 data logging. It measures CO2 concentration using non-dispersive infrared technology and provides digital output options for embedded systems.

The current page lists UART and PWM outputs, built-in temperature compensation, long service life, and a measurement range of 400ppm to 10000ppm. It can be used with the ELAB Nano V3, Raspberry Pi Pico W, or combined with particulate sensors like the YourCee PMS9103M PM2.5 Laser Dust Sensor.

For reliable CO2 readings, avoid sealing the module in stagnant air, allow warm-up, and follow the supplier guidance for calibration and ABC behavior. It is for air-quality monitoring, not life-safety or medical use.

Technical Specifications

Parameter Value
SKU YourCee-MH-Z19E1
Selected Variant MH-Z19E/Sensor (Terminal)
Gas Carbon dioxide CO2
Principle NDIR infrared absorption
Measurement Range 400ppm-10000ppm per current page
Outputs UART and PWM
Compensation Built-in temperature compensation
Service Life More than 10 years per current page
Applications HVAC, air quality, schools, offices, smart homes
Important Note Use as monitoring sensor, not a safety-certified alarm

Board Layout & Label Guide

  • VCC - Module power input according to product wiring.
  • GND - Common ground.
  • TXD - UART transmit from sensor to host RX.
  • RXD - UART receive for commands.
  • PWM - Pulse-width output representing CO2 concentration.
  • Gas Window - Keep exposed to ambient air.
  • Calibration Note - Follow supplier calibration guidance.
  • Airflow Note - Avoid sealed pockets and condensation.

Application Scenarios

1. Python UART Frame Read

Send a read command and print the returned bytes.

import serial

ser = serial.Serial("COM7", 9600, timeout=1)
cmd = bytes([0xFF, 0x01, 0x86, 0, 0, 0, 0, 0, 0x79])
ser.write(cmd)
print(ser.read(9).hex(" "))

2. Arduino UART Bridge

Forward sensor serial data for protocol debugging.

#include <SoftwareSerial.h>

SoftwareSerial co2(10, 11);

void setup() {
  Serial.begin(115200);
  co2.begin(9600);
}

void loop() {
  while (co2.available()) Serial.write(co2.read());
}

3. PWM Pulse Measurement

Measure a PWM high pulse for custom conversion logic.

const int pwmPin = 2;

void setup() {
  Serial.begin(115200);
  pinMode(pwmPin, INPUT);
}

void loop() {
  unsigned long highTime = pulseIn(pwmPin, HIGH, 2000000);
  Serial.println(highTime);
  delay(1000);
}

Packing List

  • 1 x YourCee MH-Z19E CO2 Sensor Module, terminal variant

FAQ

Q: What does it measure?
A: It measures carbon dioxide concentration in air.

Q: What technology does it use?
A: NDIR infrared gas sensing.

Q: What outputs are available?
A: The current page lists UART and PWM.

Q: What range is listed?
A: 400ppm to 10000ppm.

Q: Does it need warm-up?
A: Yes, allow stabilization before relying on readings.

Q: Can it replace a safety alarm?
A: No, use certified equipment for life-safety applications.

Q: Can I use it with Arduino?
A: Yes, through UART or PWM.

Q: Why do readings drift?
A: Airflow, calibration, temperature, and enclosure conditions can affect readings.
