RoboSense M1 Plus Solid-State LiDAR
📦 Location of the warehouse: China
Free shipping for you
Free Shipping from 30€ in Germany, 50€ in the EU!
Trustpilot rating: 4.4/5.0
Thank you for your support - rate us on Trustpilot!
RoboSense M1 Plus Solid-State LiDAR
The RoboSense M1 Plus is the world’s first intelligent variable-focus automotive-grade solid-state LiDAR. Designed for high-precision and high-reliability autonomous driving applications, it features 200m detection range, Class 1 eye safety, and ultra-high point cloud performance of up to 1,575,000 pts/s in dual return mode. With advanced AEC-Q100 certified SoC and ISO 26262 ASIL-B functional safety compliance, the M1 Plus is ideal for complex urban environments and highway scenarios.
Key Features
-
200m max range, 180m @ 10% reflectivity target (NIST standard)
-
High resolution with 0.2° × 0.1° angular precision
-
Up to 1,575,000 pts/s, ultra-dense point cloud for accurate object recognition
-
Wide FOV: 120° horizontal × 25° vertical coverage
-
Typical range accuracy: ±5 cm
-
High frame rate: 10Hz / 20Hz for flexible applications
-
AEC-Q100 & ISO26262 certified, automotive-grade reliability
-
Ingress protection: IP67 & IP6K9K, built for extreme weather
-
Wide operating temperature: -40°C ~ +85°C
-
Compact size: 111 × 110 × 45 mm, easy to integrate
-
Low latency UDP data output via 1000Base-T1 Ethernet
Technical Specifications
| Parameter | Specification |
|---|---|
| Laser Wavelength | 905nm |
| Horizontal FOV | 120° |
| Vertical FOV | 25° |
| Angular Resolution (H/V) | Avg. 0.2° / Avg. 0.2° (ROI: Avg. 0.1°) |
| Frame Rate | 10Hz / 20Hz |
| Range | 200m (180m @10% NIST) |
| Range Accuracy | ±5cm |
| Blind Spot | ≤ 0.5m |
| Output (Points/sec) | 787,500 pts/s (Single), 1,575,000 pts/s (Dual) |
| Ethernet | 1000Base-T1 |
| Protocol | UDP packets over Ethernet |
| UDP Content | Spatial Coordinates, Intensity, Timestamp, etc |
| Power Consumption | 15W |
| Operating Voltage | 9 – 16V |
| Operating Temp | -40°C ~ +85°C |
| Storage Temp | -40°C ~ +105°C |
| Time Synchronization | gPTP |
| Ingress Protection | IP67, IP6K9K |
| Dimensions (W×D×H) | 111 × 110 × 45 mm |
| Weight (w/o cable) | 690g ± 20g |
Applications
-
Autonomous driving (L2+ to L4)
-
Smart transportation systems
-
Urban mobility mapping and localization
-
ADAS and automotive perception modules
-
Roadside sensing in smart city deployments
