DAMIAO DM100 Brushless Servo Joint Motor MIT Driver Dual Encoder

DAMIAO DM100 Brushless Servo Joint Motor MIT Driver Dual Encoder

176,95 €

DAMIAO DM100 Development Kit is a comprehensive brushless servo joint motor solution designed for robotics research, automation, and advanced motion control. Featuring MIT driver technology and dual encoder feedback, it provides precise control, smooth motion, and reliable performance. This kit is ideal for developers, engineers, and research institutions working on robotic arms, exoskeletons, and intelligent automation systems.



Features

  • Brushless servo joint motor with integrated MIT driver

  • Dual encoder system for precise position and velocity feedback

  • Development kit format for rapid prototyping and testing

  • Supports closed-loop control and real-time communication

  • Compact design for robotics and automation integration

  • High reliability, low noise, long service life



Specifications

Specification Details
Model DM100
Type Brushless servo joint motor kit
Driver Technology MIT driver
Feedback Dual encoder (position + velocity)
Communication Real-time bus supported
Applications Robotics, automation, research & development
Durability High reliability, long lifespan


Name Parameters Remarks
Supply Voltage 24V (4S-12S) Absolute maximum value does not exceed 85V
MCU Core Cortex®-M4
MCU Frequency 200MHz
Communication CAN UART for parameter tuning
Control Method FOC Field-Oriented Control
Max Continuous Current 40A
Peak Current 80A
Sensor Type Magnetic Encoder
Control Modes MIT, Velocity, Position
Encoder Support Dual Encoders Supported Dual Magnetic / Single Magnetic + Hall
Recommended Motor 100 series motors



Applications

  • Robotics Research & Development Perfect for humanoid robots, quadrupeds, and robotic arms requiring precise torque and position control.

  • Exoskeletons & Wearable Robotics Provides smooth motion and reliable feedback for assistive devices and rehabilitation systems.

  • Industrial Automation Torque‑controlled actuators for smart manufacturing, CNC systems, and automated assembly lines.

  • Educational & Prototyping Platforms Universities and labs can use the kit for motion control experiments, algorithm testing, and actuator prototyping.

  • Intelligent Motion Control Projects Suitable for projects requiring closed‑loop control, real‑time communication, and high reliability.



Packing List

DAMIAO DM100 Brushless Servo Joint Motor MIT Driver Dual Encoder x 1
