M5Stack RCA Audio/Video Composite Unit
The M5Stack RCA Audio/Video Composite Unit is a specialized component designed for seamless analog signal transmission in multimedia applications. This RCA unit features a female jack terminal block configuration that supports standard composite video and stereo audio connections. Whether you're working on DIY electronics, embedded systems, or multimedia setups, this unit offers a dependable interface for your audio/video needs.
What is the RCA Audio/Video Composite Unit?
The RCA Audio/Video Composite Unit enables users to transmit both video and stereo audio signals from a source device to an output terminal. It includes three jacks:
-
Yellow – for composite video
-
Red – for right audio channel
-
White – for left audio channel
This classic RCA interface is widely used in consumer electronics, making it easy to integrate into your existing A/V systems.
Designed for M5Stack Integration
As part of the M5Stack Unit series, the M5Stack RCA Audio/Video unit is optimized for compatibility with M5Stack development kits and controllers. It’s ideal for prototyping projects involving media output, IoT displays, or retro gaming setups.
Features of M5Stack RCA Audio/Video Composite Unit
-
Composite video transmission – Ensures smooth analog video signal output
-
RCA Female jack terminal block – Standard A/V interface for easy connectivity
-
A/V connector – Supports stereo audio and composite video signals
-
Internal dual-channel switching – Efficient signal routing for stable performance
-
HY2.0 4P interface – Easy connection with M5Stack cores and units
-
2x LEGO compatible holes – Enables modular mounting and physical integration
Includes
- 1x RCA Unit
- 1x HY2.0-4P Cable
Applications
- RCA stereo output
- Composite video or audio output
- M5Stack-based media output projects
- Analog A/V streaming systems
- Home electronics interfacing
- Signal testing and multimedia education setups
Specification
| Resources | Parameters |
|---|---|
| interface | RCA female seat |
| switch | Internal dual-channel switching |
| Product Size | 37mm × 24mm × 8mm |
| Package Size | 136mm × 92mm × 13mm |
| Product Weight | 5.4g |
| Package Weight | 10.6g |
