AMS1117-1.2V/1.5V/1.8V/2.5V/3.3V/5V Step-Down Power Module
The Voltage Regulator Module is a compact and efficient solution for powering electronic projects. It offers a variety of output voltages—1.2V, 1.5V, 1.8V, 2.5V, 3.3V, and 5.0V—from an input voltage range of 2.75V - 12V. This module supports a maximum output current of 800mA, making it suitable for single-chip designs and embedded systems.
Key Features:
- Wide Input Range: Supports input voltages from 2.75V to 12V.
- Multiple Output Voltages: Provides 1.2V, 1.5V, 1.8V, 2.5V, 3.3V, and 5V output options.
- Maximum Current: 800mA output across all voltage settings.
- Stable Voltage Regulation: With 3% stability, ensuring consistent performance.
- Easy Integration: Equipped with 2P single-row pin headers for both input and output connections.
- Compact Size: PCB size is 2.5cm x 1.1cm, perfect for tight spaces.
- Pin Fixing Holes: 3.2mm pin holes for easy mounting on hole plates for expansion experiments.
- Power Indicator: Red power LED for easy status checking.
Specifications:
| Specification | Value |
|---|---|
| Input Voltage | 2.75V - 12V |
| Output Voltages | 1.2V, 1.5V, 1.8V, 2.5V, 3.3V, 5.0V |
| Maximum Output Current | 800mA |
| Voltage Stability | 3% |
| Pin Fixing Holes | 3.2mm |
| PCB Size | 2.5cm x 1.1cm |
| Weight | 2g |
Applications:
This module is ideal for:
- Single-chip designs
- Embedded systems
- Prototyping and testing electronic circuits
- Powering electronic devices with varying voltage requirements
