Ai-Thinker GP-02-Kit GPS/BDS/GNSS Development Board
The GP-02-Kit is a high-performance BDS/GNSS multi-mode satellite navigation receiver SoC module, designed for precise positioning and navigation applications. It integrates an RF front-end, a digital baseband processor, a 32-bit RISC CPU, and power management features, ensuring accurate and efficient performance. The module supports China’s Beidou (BDS), the United States’ GPS, and Russia’s GLONASS satellite navigation systems, enabling multi-system joint positioning.
Ideal for applications requiring high-precision navigation, real-time tracking, and low-power operation, the GP-02-Kit is widely used in smart transportation, IoT tracking, autonomous vehicles, and geolocation-based services.
Key Features of GP-02-Kit
- Multi-System GNSS Support
Compatible with BDS (Beidou), GPS, and GLONASS for enhanced positioning accuracy and global coverage.
- High-Performance 32-bit RISC CPU
Ensures efficient processing of satellite signals, low power consumption, and fast acquisition times.
- Wide Power Supply Range
Operates on a 5V power supply, making it easy to integrate into various embedded systems.
- High-Speed Serial Communication
Supports UART serial communication with a maximum baud rate of 256000bps.
- Compact & Robust Design
- SMD-6 form factor, ensuring easy integration into compact devices.
- Industrial-grade temperature tolerance (-40°C to 85°C), suitable for harsh environments.
-
Storage temperature up to 125°C, maintaining stability in extreme conditions.
Technical Specifications
| Parameter | Details |
|---|---|
| Model | GP-02-Kit |
| Size | 20.3 × 18.0 × 3.1mm (±0.2mm) |
| Operating Temperature | -40°C to 85°C |
| Storage Environment | -40°C to 125°C, <90% RH |
| Power Supply | 5V |
| Serial Port Speed | Up to 256000bps |
| Certification | RoHS |
| Form Factor | SMD-6 |
Pin Definition & Function
The GP-02 module has a total of 18 interfaces. As shown in the pin diagram, thepinfunction definition table is the interface definition.
| Pin No. | Name | Function Description |
|---|---|---|
| 1 | N/F | Shutdown control, remains high during normal operation (internal pull-up) |
| 2 | RX0 | General GPIO, default UART0 RXD |
| 3 | TX0 | General GPIO, default UART0 TXD |
| 4 | GND | Grounded |
| 5 | VCC | 5V Power Supply |
| 6 | PPS | Time Pulse Signal Output |
Dimensions
Why Choose GP-02-Kit?
- High-Precision Positioning with multi-GNSS support (BDS, GPS, GLONASS).
- Low Power Consumption with an optimized 32-bit RISC CPU.
- Fast Acquisition Time for real-time navigation and tracking.
- Industrial-Grade Reliability with -40°C to 85°C operating temperature.
- Compact SMD-6 Form Factor for easy integration into IoT and embedded systems.
Applications of GP-02-Kit
The GP-02-Kit is ideal for applications requiring precise navigation and tracking, such as:
- IoT & Asset Tracking (logistics, fleet management, personal tracking).
- Smart Transportation (autonomous vehicles, vehicle positioning systems).
- Geolocation-Based Applications (drones, outdoor navigation, mapping services).
- Security & Surveillance (location-based security systems).
