1080P HD Outdoor Waterproof CVBS Analog Camera is an equipment with HD outdoor waterproof monitor, mobile phone remote control, and coaxial wired camera head.
Product Parameter
| Parameter | Value |
|---|---|
| Model | DS-2CE16C3T-ITS |
| Name | 1.3 Mega Progressive Scan CMOS |
| Total Pixels | 1280(horizontal) x 960(vertical) |
| Minimum Illumination | 0.01 Lux @(F1.2, AGC ON), 0 Lux with IR |
| Shutter | 1/25 s to 1/100,000 s |
| Lens | 3.6mm(2.8mm, 6mm, 8mm, 12mm, 16mm optional) |
| Lens Mount Type | M12 |
| Day & Night Switch Mode | ICR infrared cut-filter switch |
| Synchronization Mode | Internal synchronization |
| Frame Rate | 720p @25fps |
| HD Video Output | 1-way BNC coaxial high-definition, in line with HDTV standards |
| CVBS Video Output | 1-way 1Vp-p Composite Output(75Ω)/BNC |
| S/N Ratio | Greater than 62dB |
| Operating Temperature and Humidity | -40°C ~ 60°C, humidity less than 90%(non - condensing) |
| Power Supply | DC12V±15% |
| Infrared Distance | 50 - 80m |
| Power Consumption | 4W MAX |
| Protection Level | IP66 |
| Size(mm) | 87.26x86.78x157.14 |
| Weight | 700g |
Different focal length lens screen reference
