Waveshare 7inch Capacitive Touch Screen LCD (H) 1024×600
Description
Waveshare 7inch HDMI LCD (H) is a versatile 7inch capacitive touch display featuring an 800 × 480 IPS panel, HDMI input, and USB touch control. It is designed for Raspberry Pi, Jetson Nano, Windows PCs, and game consoles, making it a practical option for touch interfaces, portable monitors, embedded control panels, and multimedia display projects.
The display supports up to 5-point capacitive touch, a 178° wide viewing angle, OSD menu control, and audio output through HDMI with both a 3.5mm audio jack and 4PIN speaker header. It is well suited for developers who need a compact external touch display with broad platform compatibility.

Features
- 7inch IPS display with 800 × 480 hardware resolution.
- Capacitive touch with up to 5-point touch support.
- HDMI input for wide compatibility across embedded and desktop devices.
- USB touch interface for easy touch connectivity.
- 178° viewing angle for clear visibility from different directions.
- OSD menu for brightness, contrast, and power management adjustments.
- Audio output support through 3.5mm jack and 4PIN speaker header.
- Driver-free support for Raspberry Pi, Windows, Jetson Nano, and more.
Specifications
| Display size | 7inch | Hardware resolution | 800 × 480 |
|---|---|---|---|
| Display panel | IPS | Viewing angle | 178° |
| Touch type | Capacitive touch | Touch points | Up to 5-point |
| Video input | HDMI | Touch interface | USB |
| Audio output | 3.5mm jack, 4PIN speaker header | Power input | 5V |
| Compatible systems | Raspberry Pi OS, Ubuntu, Kali, Retropie, Windows 11/10/8.1/8/7 | Compatible platforms | Raspberry Pi, Jetson Nano, Windows PC, game consoles |
Applications
This 7inch HDMI touch display is ideal for Raspberry Pi touch interfaces, Jetson Nano edge AI displays, portable HDMI monitors, industrial HMI, embedded debugging displays, media control panels, and game console auxiliary screens.


Product List
| Item | Quantity |
|---|---|
| 7inch HDMI LCD (H) | 1 |
| HDMI Cable | 1 |
| HDMI to Micro HDMI Adapter | 1 |
| USB Type A to Micro B Cable | 1 |
Other Content
Touch control, display quality, and mechanical dimensions are especially important on this display because it is often used as a front-end touch terminal or portable monitor. These official images help when planning interaction, installation, and enclosure fitment.



Resources
- Waveshare 7inch HDMI LCD (H) Wiki
- Waveshare 7inch HDMI LCD (H) User Manual
- Waveshare 7inch HDMI LCD (H) Mechanical Drawing
- Raspberry Pi Official Documentation
- Waveshare LCD Common Questions
FAQ
Does this display support touch?
Yes. It supports capacitive touch with up to 5-point touch depending on the system.
What input interface does this display use?
It uses HDMI for video and USB for touch.
Can it work with Raspberry Pi and Jetson Nano?
Yes. It supports Raspberry Pi, Jetson Nano, Windows PCs, and several other compatible devices.
What kinds of projects is it best for?
It is ideal for Raspberry Pi touch dashboards, portable HDMI monitors, industrial interfaces, Jetson development displays, and multimedia touch applications.
