note: Due to the problem of the characteristics of the ink screen, it cannot be partially refreshed for a long time, otherwise, it will leave residual images and lead to irreversible damage.
Specifications
| MCU | ESP32-S3-WROOM-1-N16R8 |
| Wireless Connectivity | Wi-fi Bluetooth V5.0 |
| Programming Environment | Arduino-ide VS Code |
| Onboard Functions | |
| Flash | 16MB |
| PSRAM | 8MB |
| Support PCF8563 RTC | Battery capacity detection |
| 4 . 7-inch Ultra-low Power E-paper |
| Driver IC | EDO47TC1 |
| Size | 4.7 inch |
| Gray levels | 16 |
| Resolution | 540 x 960 pixels |
| Ultra Wide viewing angle | low power consumption |
Sample Code For Reference [Github]
If you need technical support please check the link below for more details.
Product Pin Diagram
Touch Version
Basic Version
Shipping List
Touch Version
Basic Version
