NOTE: This product is priced including tax for the European region.
Just as good, but better
With a higher core clock speed, double the memory, more powerful Arm cores, optional RISC‑V cores, new security features, and upgraded interfacing capabilities, Raspberry Pi Pico 2 delivers a significant performance boost while retaining compatibility with earlier members of the Raspberry Pi Pico series.
Programmable in C / C++ and Python, and with detailed documentation, Raspberry Pi Pico 2 is the ideal microcontroller board for enthusiasts and professional developers alike.
Chip off the new block
Raspberry Pi Pico 2 is powered by RP2350, our new high-performance, secure microcontroller. Every aspect of the design has been upgraded, from the CPU cores to our unique PIO interfacing subsystem. We’ve introduced a comprehensive security architecture, built around Arm TrustZone for Cortex-M. And new low-power states and package options expand the range of addressable applications.
Switch it up
The unique dual-core, dual-architecture capability of RP2350 allows users to choose between a pair of industry-standard Arm Cortex-M33 cores, and a pair of open-hardware Hazard3 cores, giving developers a chance to experiment with the RISC‑V architecture in a stable, well-supported environment.
Radical transparency
The RP2350 security architecture, including the secure boot ROM, are extensively documented and available to all users without restriction: this transparent approach, which contrasts with the “security through obscurity” offered by legacy vendors, allows professional users to integrate RP2350, and Raspberry Pi Pico 2, into products with confidence.
Robust and fully documented security features:
- Optional boot signing, enforced by on-chip mask ROM, with key fingerprint in OTP
- Protected OTP storage for optional boot decryption key
- Global bus filtering based on Arm or RISC-V security/privilege levels
- Peripherals, GPIOs, and DMA channels individually assignable to security domains
- Hardware mitigations for fault injection attacks
- Hardware SHA-256 accelerator
Specification
- Dual Arm Cortex-M33 or dual Hazard3 processors @ 150MHz
- 520 KB on-chip SRAM
- Software- and hardware-compatible with Raspberry Pi Pico 1
- Drag-and-drop programming using mass storage over USB
- Castellated module allows soldering direct to carrier boards
- 2 × UART
- 2 × SPI controllers
- 2 × I2C controllers
- 24 × PWM channels
- 4 x ADC channels
- 1 × USB 1.1 controller and PHY, with host and device support
- 12 × PIO state machines
- Open source C/C++ SDK, MicroPython support
- Operating temperature -20°C to +85°C
- Supported input voltage 1.8–5.5V DC
Documents
Resources
- Raspberry Pi Pico 2 announcement blog post
- Raspberry Pi Pico 2 Pinout
- Raspberry Pi Product Information Portal (PIP)
- RP2350 Information
- Our Raspberry Pi Pico Tutorials
- Micropython website
- Raspberry Pi Pico 2 STEP file
- Raspberry Pi Pico 2 Fritzing part
- Raspberry Pi Pico 2 design files (Cadence Allegro)
