The Raspberry Pi 500 offers the ultimate compact PC experience in a premium keyboard form factor. Powered by a fast quad-core processor and 8GB of RAM, it delivers smooth 4K dual-display performance for all your computing needs.
Feature
- Powerful Performance: 2.4GHz quad-core 64-bit Arm Cortex-A76 CPU with 8GB RAM
- Dual 4K Displays: 2 micro HDMI ports supporting resolutions up to 4Kp60
- Comprehensive Connectivity: Dual-band Wi-Fi, Bluetooth 5.0, Gigabit Ethernet, USB 3.0
- High-Quality Keyboard: Integrated 78/79/83-key compact keyboard (regional variants)
- Effective Cooling: Built-in aluminum heatsink for optimum thermal management
- Compact Form Factor: All-in-one computer and keyboard design for space efficiency
Specification
|
Keyboard |
DE |
|
Processor |
2.4GHz quad-core 64-bit Arm Cortex-A76 CPU, with cryptography extensions, 512KB per-core L2 caches and a 2MB shared L3 cache |
|
Memory |
8GB LPDDR4X-4267 SDRAM |
|
Storage |
32GB Raspberry Pi A2-Class Micro-SD card |
|
Wi-Fi |
Dual-band (2.4GHz and 5.0GHz) IEEE 802.11b/g/n/ac |
|
Bluetooth |
Bluetooth 5.0, BLE |
|
Ethernet |
1x Gigabit Ethernet |
|
USB |
2x USB 3.0 1x USB 2.0 |
|
GPIO |
Horizontal 40-pin GPIO header |
|
Video & sound |
2 × micro HDMI ports (supports up to 4Kp60) |
|
Multimedia |
H.265 (4Kp60 decode); OpenGL ES 3.0 graphics |
|
SD card support |
microSD card slot for operating system and data storage |
|
Keyboard |
78-, 79- or 83-key compact keyboard (depending on regional variant) |
|
Power |
5V DC via USB connector |
|
Operating temperature |
0°C to +50°C |
|
Dimensions |
286 mm × 122 mm × 23 mm (maximum) |
|
Production lifetime |
Raspberry Pi 500 will remain in production until at least January 2034 |
|
Compliance |
For a full list of local and regional product approvals, please visit pip.raspberrypi.com |
Hardware Overview
If you need a UK version or US version, please contact us first.
Keyboard print layouts
