Orbbec Gemini 2L Stereo Vision Camera with Active IR Technology

EU
Sale price €449,95
incl. VAT
SKU: ORBBEC-Gemini-2L
Add to Wishlist Add to Compare
Visa
PayPal
Mastercard
American Express
Shop Pay
ORBBEC-Gemini 2 L-1

Orbbec Gemini 2L Stereo Vision Camera with Active IR Technology

€449,95

Shipping & Delivery Information

🚚 In-Stock Items: Orders for in-stock products are shipped within 24 hours after the order is placed.

📦 Pre-order Items: If a product is marked as "Pre-order", it means it is currently out of stock. We'll dispatch your order once we have restocked, usually within 10 working days. For special pre-sale items, the expected arrival date will be noted in the product description.

✈️ Express Shipping: Need your order urgently? Please contact us via email or live chat, and we’ll help arrange express delivery for you.

🔍 Orbbec Gemini 2L: Precision Depth in Every Frame

The Gemini 2L is powered by advanced active stereo IR technology 🔦 with a 100mm baseline, and features Orbbec’s latest custom ASIC 🧠 for high-quality depth processing.

  • 📐 Wide Diagonal Depth FoV: Up to 101° for expansive scene coverage

  • 🔌 Single USB 3.0 Cable: Streamlined power + data connectivity in one cable


📏 Close-Range Accuracy, No Blind Spots

Equipped with a proximity sensor for single-point ranging, Gemini 2L eliminates depth blind zones within the 0–10m range—ideal for tight indoor spaces or precision robotics 🤖.


🧭 Built-in IMU for Motion Awareness

An internal IMU enables motion and position tracking, making it perfect for dynamic environments and mobile platforms 🚶♂️🚗.


🌗 Lighting Versatility

From pitch-dark rooms to semi-outdoor scenes, Gemini 2L delivers reliable depth data with ease—fully supported by the intuitive Orbbec SDK 💻.



Features

    📸 Gemini 2L: Precision Vision, Engineered for Depth

    • 🟥🟦 Global Shutter for both RGB and IR cameras—capturing fast motion with minimal distortion

    • 🌐 Wide Field of View: 91° Horizontal × 66° Vertical for expansive scene coverage

    • 📏 High-Quality Depth Output: Accurate from 0.25m to 10m

    • 🎞️ Up to 30 fps at 1280 × 800 depth resolution for smooth, real-time data

    • 🔌 USB Type-C for streamlined power + data connectivity

    • 🧭 Built-in IMU for motion and orientation tracking

    • 🔗 Multi-Camera Sync for scalable, synchronized deployments

    • 🌄 Broad Scene Coverage powered by a custom ASIC, delivering up to 101° depth FoV and 90°+ D2C FoV


    🎯 Depth Accuracy That Delivers

    With a 100mm stereo baseline, Gemini 2L achieves a Root Mean Squared Error (RMSE) < 2% at 4 meters—ensuring dependable performance for 3D reconstruction, robotics, and precision measurement tasks.


    📏 Consistent Depth Measurement Gemini 2L features a close-range single-point ranging function, ensuring stable depth data across the 0–10m range—with no blind spots. Perfect for precision tasks in confined or dynamic environments.


    🎯 Accurate Frame Synchronization Enjoy precise alignment of depth and RGB frames, plus support for multi-device synchronization—ideal for setups requiring multi-angle coverage or wide-area 3D capture.

    🚀 Reliable in Motion-Heavy Environments Gemini 2L integrates a 6-axis IMU 🧭 for real-time motion and orientation tracking, ensuring stable performance even in fast-moving or dynamic scenes. Paired with a global shutter 📸 that delivers uniform exposure across all pixels, it effectively reduces motion blur and distortion—ideal for robotics, AR/VR, and mobile platforms.


    🎛️ Adaptive Scene-Based Modes With built-in scene-based working modes, Gemini 2L intelligently adjusts to diverse application scenarios. The Dimensioning mode 📐 is especially valuable for measurement and 3D reconstruction, providing developers with practical tools for precision-driven product design.



    Gemini 2L Specifications

    Parameter Specification
    Depth Technology Active Stereo IR
    Wavelength 850nm
    Depth Range 0.2 - 10m
    Depth Resolution/FPS Up to 1280X800@30fps
    Depth FOV H91° V66°
    RGB Resolution/FPS Up to 1280X800@30fps
    RGB FOV H94° V68°
    Processing Orbbec ASIC
    IMU Supported

    *Precision: ≤ 2% @ 4m

    Physical Parameters

    Parameter Specification
    Data Connection USB 3.0 & USB 2.0
    Power Input DC 5V ± 2.0A
    Trigger Supported
    Power Consumption Typical average < 3.0W/Max peak value < 10.0W
    Operating Environment 0℃ - 40℃, 8%RH - 90%RH (non - condensing), Indoor/Semi - Outdoor
    SDK Support Orbbec SDK
    Data Output Point Cloud, Depth Map, IR & RGB
    Dimensions (WHD) 124mm x 29mm x 26 mm ± 0.5mm
    Weight 152g ± 2g
    Installation 1 x 1/4 - 20 UNC thread mounting point 2 x M3 thread mounting points



    Applications

    🚗 AMR (Autonomous Mobile Robots) Real-time 3D mapping 🗺️ and navigation capabilities, powered by advanced object detection and avoidance 🤖—ensuring safe and efficient movement in dynamic environments.


    🤝 Cobot (Collaborative Robots) Depth sensing enables Cobots to intuitively respond to human gestures and commands, fostering safe, natural interaction in shared workspaces 🧍♂️🤖.


    🔧 Automated Assembly High-precision 3D data capture and analysis drives smarter automated assembly workflows—minimizing errors, boosting productivity, and accelerating throughput ⚙️📈.



    Difference Between Gemini 2 L and Gemini E Lite

    Parameters

    Gemini 2 L

    Gemini E Lite

    Depth Technology Active Stereo IR Active Stereo IR
    Wavelength 850nm 940nm
    Depth Range 0.2-10m *0.2-2.5m
    Depth Resolution/FPS Up to 1280X800@30fps Up to 640X480@30fps
    Depth FOV H91° V66° H79° V62°
    RGB Resolution/FPS Up to 1280X800@30fps N/A
    RGB FOV H 94° V 68° N/A
    Processing Orbbec ASIC Orbbec ASIC
    IMU Supported N/A
    Data Connection USB 3.0 & USB 2.0 USB 2.0 Type-C
    Power Input DC 5V ≥2.0A USB 2.0 Type-C
    Trigger Supported N/A
    Power Consumption Typical average < 3.0W/Max peak value < 10.0W Average <1.2W
    Operating Environment 0℃ - 40℃, 8%RH - 90 %RH (non-condensing), Indoor/Semi-Outdoor 10℃ - 40℃; Indoor; 10%-95%RH (non-condensing)
    SDK Support Orbbec SDK Orbbec OpenNI SDK
    Data Output Point Cloud, Depth Map, IR & RGB Point Cloud, Depth Map, IR & RGB
    Dimensions (W*H*D) 124mm x 29mm x 26 mm ± 0.5mm 90mm x 25mm x 25mm
    Weight 152g ± 2g 88g
    Installation 1 x 1/4-20 UNC thread mounting point 2 x M3 thread mounting points 2 x M2
