The MYZR I.MX8 CB300 is a high-performance quad-core ARM Cortex-A53 core board designed for industrial and commercial applications. With robust processing power, a compact design, and efficient heat dissipation, this board is suitable for AI computing, industrial automation, smart cities, and multimedia applications.
Key Features
- Quad-core ARM Cortex-A53 processor with a clock speed of 1.5GHz
- Integrated heatsink for enhanced cooling and stable performance under high-load conditions
- 2GB DDR4 RAM and 8GB eMMC storage for fast and reliable operation
- Comprehensive connectivity including Ethernet, USB 3.0, PCIe, I2C, SPI, UART, and HDMI
- Rich multimedia support with HDMI 2.0a (4K@60Hz), MIPI-DSI, and MIPI-CSI for high-quality video and camera applications
- Wide operating temperature range, supporting both commercial (0°C to 70°C) and industrial (-40°C to 85°C) environments
Technical Specifications
| Specification | Details |
|---|---|
| Processor | NXP i.MX8M Quad (ARM Cortex-A53) |
| Coprocessor | Cortex-M4 for low-power tasks |
| Memory | 2GB DDR4 |
| Storage | 8GB eMMC |
| Cooling System | Integrated heatsink for improved thermal performance |
| Interfaces | USB 3.0, PCIe, I2C, SPI, UART, HDMI, MIPI-DSI, MIPI-CSI, GPIO |
| Ethernet | 1x 10/100/1000Mbps |
| Display Support | HDMI 4K@60Hz, MIPI-DSI |
| Camera Support | MIPI-CSI |
| Operating System | Linux 4.14.98, Android 9.0 |
| Power Supply | 3.3V / 5V |
| Board Size | 52mm x 52mm |
| Temperature Range | 0°C to 70°C (commercial), -40°C to 85°C (industrial) |
Applications
- Edge computing
- Industrial automation
- Smart city solutions
- Multimedia processing
- AI and machine learning
- Human-machine interfaces (HMI)
- IoT and smart devices
- Embedded vision and camera applications
