High-resolution E-Paper 2.66 inch Four Color E-Ink Display

Function

• Refresh Method: Full refresh for 20s
• Display direction: Horizontal or vertical

Parameters

• Product size: 2.66 inch
• Resolution: 360x184
• PPI: 151.99
• Color: Black, White, Yellow and Red
• Driver IC: JD79667
• Interface: SPI
• Operating temperature: 0-40 ℃

Features

• Display feature: Bistable display (retains the current content after a power outage)
• Display mode: Pure reflection
• Viewing angle: Wide viewing angle exceeding 170 degrees
• Surface Treatment: Hard-coated for anti-glare effects
• Energy conservation: No power consumption when not refreshing the screen
• Eye Protection: No blue light emission, zero radiation
