DAMIAO J3507-2EC Brushless Servo Joint Motor 1Nm MIT Driver Dual Encoder

DAMIAO J3507-2EC Brushless Servo Joint Motor 1Nm MIT Driver Dual Encoder

DAMIAO J3507‑2EC Brushless Servo Joint Motor is a compact and high-efficiency actuator designed for precision robotics and intelligent automation. With a built-in MIT driver and dual magnetic encoders, it delivers absolute single-turn position feedback and maintains accuracy even after power loss. The motor supports CAN FD communication up to 5Mbps and offers real-time feedback on speed, torque, position, and temperature. Engineered for low-speed, high-torque performance, it features multiple control modes, including force-position hybrid control, and is protected by a robust set of thermal, voltage, and current safeguards. Its lightweight structure and small footprint make it ideal for space-constrained applications.



Features

  • Dual Encoder: Provides absolute single-turn position feedback; retains accuracy even after power loss.

  • Integrated Design: Motor and MIT driver combined into a compact, high-integration unit.

  • Visual Debugging: Supports PC-based parameter tuning and firmware upgrades.

  • CAN FD Support: Compatible with CAN FD protocol, up to 5Mbps baud rate.

  • Real-time Feedback via CAN Bus: Speed, position, torque, and temperature data available.

  • Dual Temperature Protection: Ensures safe operation under thermal stress.

  • High Torque at Low Speed: Optimized for low-speed, high-torque applications.

  • Flexible Control Modes: Supports multiple control modes for versatile use cases.



Specifications

Category Parameter Value / Description
Electrical Specs Rated Voltage 24V
Rated Phase (Power) Current 3.0A (1.2A)
Peak Phase (Power) Current 8.3A (4A)
Motor Performance Rated Torque 0.8Nm
Peak Torque 3Nm
Rated Speed 150rpm
Max No-load Speed 460rpm
Gear Ratio 7:01
Motor Properties Pole Pairs 14
Phase Inductance 235µH
Phase Resistance 0.8Ω
Structure & Weight Outer Diameter 46mm
Height 37.9mm
Motor Weight Approx. 150g
Encoder Resolution 14-bit
Quantity 2
Type Magnetic encoder (single-turn absolute)
Communication Control Interface CAN
Tuning Interface UART @ 921600bps
Control Modes Supported Modes MIT Mode, Speed Mode, Position Mode, Force-Position Hybrid Mode
Protection Driver Over-temp Protection 120°C – exits enabled mode
Motor Over-temp Protection User-defined (recommended ≤100°C)
Over-voltage Protection User-defined (recommended ≤30V)
Communication Loss Protection Exits enabled mode if no CAN command
Over-current Protection User-defined (recommended ≤9.8A)
Under-voltage Protection Exits enabled mode if voltage <15V





Applications

  • Robotic joints and collaborative arms requiring compact size and precise motion control

  • Miniature AGVs and mobile platforms where low-speed torque and thermal safety are critical

  • Precision automation systems with multi-axis coordination and real-time feedback needs

  • Educational and research robotics for advanced control experiments and prototyping

  • Medical and wearable robotics where lightweight and high-integration motors are essential



Packing List

Item Quantity Description
Motor (with integrated driver) ×1 DAMIAO J3507‑2EC brushless servo motor with MIT driver
Power & CAN Communication Cable ×1 SH1.0 8-pin connector cable, 200mm
UART Debug Cable ×1 SH1.0 3-pin connector cable, 200mm
