M5Stack M5StickC ADC Hat ADS1110 V1.1

M5Stack M5StickC ADC Hat ADS1110 V1.1

14,44 €

Hat ADC v1.1 is an AD conversion module compatible with M5SticKC, internally integrating the ADC conversion chip ADS1110. It features full differential, 16-bit, self-calibration, and Δ-Σ analog/digital conversion, allowing users to easily obtain precise measurement results. The ADS1110 includes a Δ-Σ A/D converter core with adjustable gain, a clock generator, and an I2C interface, allowing for -5 ~ +5V differential input. However, through the design of the peripheral circuit of this IC, we limit the input to 0 ~ 12V.



Features

  • Input Voltage: 0-12V
  • Development Platform: Arduino, UIFlow (Blockly, MicroPython)
  • ADS1110:

16-bit no missing codes

Continuous self-calibration

Single-cycle conversion

Built-in programmable gain amplifier (gain = 1, 2, 4, 8)

Internal system clock

Programmable data rate: 8SPS to 128SPS

Internal system clock

I2C Interface @ Address: 0x48



Includes

  • 1 x Hat ADC v1.1
  • 1 x VH3.96-2P Terminal



Applications

  • Analog signal capture


Specifications



Specification Parameter
Net Weight 6g
Gross Weight 14g
Product Size 24 x 25 x 13mm
Package Size 40 x 42 x 30mm

Preview


PinMap

M5StickC G0 G26 5V GND
ADC HAT V1.1 SDA SCL 5V GND



Easyloader

Hat ADC v1.1 Easyloader
