E Ink Display's Basic Function
- Refresh method: Full refresh for 18s
- Display orientation: Horizontal or vertical
E Ink Display's Basic Parameters
- Product size: 3.5 inch
- Resolution: 384x184
- PPI: 121.66
- Color: Black, White, Red and Yellow
- Driver IC: JD79667AA
- Interface: SPI
- Operating voltage: 3.3V
- Operating temperature: 0-40 ℃
E Ink Display's Main Features
- Display feature: Bistable display (retains the current content after a power outage)
- Display mode: Pure reflection
- Viewing angle: Wide viewing angle exceeding 170 degrees
- Surface Treatment: Hard-coated for anti-glare effects
- Energy conservation: No power consumption when not refreshing the screen
- Eye Protection: No blue light emission, zero radiation
PARAMETERS
| PART NUMBER | GDEM035F51 |
| SIZE | 3.5 inch |
| TYPE | Dot Matrix |
| IC | JD79667AA |
| RESOLUTION | 384x184 |
| PPI | 121.66 |
| OUTLINE SIZE(mm) | 91.75x45.03x1.0 |
| ACTIVE SIZE(mm) | 79.68x38.18 |
| PIXEL PITCH(mm) | 0.2075x0.2075 |
| OPERATING TEMP. | 0℃~40℃ |
| STORAGE TEMP. | -25℃~70℃ |
| CONNECTOR | 24 Pin 0.5mm |
| COLOR | Black, White, Red, Yellow |
| INTERFACE | SPI |
| FULL UPDATE TIME(s) | 18 |
