Meshtastic

Meshtastic is an open-source, decentralized communication system that uses LoRa (Long Range) radio technology to enable off-grid messaging without relying on cellular networks or the internet. It is designed for outdoor enthusiasts, emergency responders, and anyone needing reliable communication in remote areas.

Feature Description
Long-Range Communication Supports distances up to 331 km in optimal conditions.
Mesh Networking Devices relay messages to extend coverage, ensuring connectivity even in difficult terrain.
Low Power Consumption LoRa technology allows devices to operate for extended periods on battery power.
Encrypted Messaging Secure communication using AES-256 encryption.
GPS Integration Supports location sharing for navigation and tracking.
No Dedicated Router Needed Works without centralized infrastructure, making it ideal for disaster scenarios.
Bluetooth Connectivity Allows easy pairing with smartphones for configuration and messaging.
Multi-Channel Support Users can create multiple encrypted channels for different groups.
Open-Source & Community-Driven Constantly evolving with contributions from developers worldwide.

Produkty dla Meshtastic

Najczęściej zadawane pytania dotyczące Meshtastic

Meshtastic to otwartoźródłowa platforma zaprojektowana do ułatwienia komunikacji na duże odległości przy niskim zużyciu energii, wykorzystująca technologię LoRa. Umożliwia urządzeniom Meshtastic bezproblemową wymianę danych bez polegania na konwencjonalnej infrastrukturze, takiej jak sieci komórkowe czy Wi-Fi, co czyni ją idealną do łączności poza siecią w odległych rejonach.
Meshtastic jest dostępny zarówno dla użytkowników bez licencji, jak i licencjonowanych operatorów radioamatorów, umożliwiając płynną komunikację dzięki swojej otwartoźródłowej, długodystansowej sieci mesh LoRa.
Tak, Meshtastic to darmowy i otwartoźródłowy projekt. Musisz jedynie zakupić urządzenia sprzętowe kompatybilne z Meshtastic, ponieważ oprogramowanie, firmware i oficjalna dokumentacja są całkowicie bezpłatne. Jeśli uważasz Meshtastic za wartościowy, rozważ wsparcie deweloperów poprzez darowiznę, aby pomóc w utrzymaniu projektu.
Meshtastic wyróżnia się zaawansowaną siecią mesh, długodystansowym przesyłaniem wiadomości tekstowych, udostępnianiem GPS i telemetrii oraz energooszczędną pracą. W przeciwieństwie do tego, krótkofalówki PMR oferują prostą, natychmiastową komunikację głosową, przyjazną dla użytkownika funkcjonalność oraz szeroką dostępność.

Meshtastic Region Codes


Region Code Description Frequency Range (MHz) Duty Cycle (%) Power Limit (dBm)
UNSET Unset N/A N/A N/A
US United States 902.0 - 928.0 100 30
EU_433 European Union 433MHz 433.0 - 434.0 10 12
EU_868 European Union 868MHz 869.4 - 869.65 10 27
CN China 470.0 - 510.0 100 19
JP Japan 920.8 - 927.8 100 16
ANZ Australia & New Zealand 915.0 - 928.0 100 30
KR Korea 920.0 - 923.0 N/A N/A
TW Taiwan 920.0 - 925.0 100 27
RU Russia 868.7 - 869.2 100 20
IN India 865.0 - 867.0 100 30
NZ_865 New Zealand 865MHz 864.0 - 868.0 100 36
TH Thailand 920.0 - 925.0 100 16
UA_433 Ukraine 433MHz 433.0 - 434.7 10 10
UA_868 Ukraine 868MHz 868.0 - 868.6 1 14
MY_433 Malaysia 433MHz 433.0 - 435.0 100 20
MY_919 Malaysia 919MHz 919.0 - 924.0 100 27
SG_923 Singapore 923MHz 917.0 - 925.0 100 20
LORA_24 2.4 GHz band worldwide 2400.0 - 2483.5 100 10

Meshtastic Radio Configuration


Name Description
Bluetooth The bluetooth config options are: Enabled, Pairing Mode and Fixed PIN.
Channels The channels config options are: Index, Role and Settings.
Device The device config options are: Device Role, Serial Output, Debug Log and Factory Reset.
Display The display config options are: Screen On Duration, Auto Carousel Interval, Always Point North, and GPS Format.
LoRa The LoRa config options are: Region, Modem Preset, Max Hops, Transmit Power, Bandwidth, Spread Factor, Coding Rate, Frequency Offset, Transmit Disabled and Ignore Incoming Array.
Network The network config options are: WiFi Enabled, WiFi SSID, WiFi PSK, WiFi Mode and NTP Server.
Position The position config options are: GPS Enabled, GPS Update Interval, GPS Attempt Time, Fixed Position, Smart Broadcast, Broadcast Interval and Position Packet Flags.
Power The power config options are: Charge Current, Power Saving, Shutdown after losing power, ADC Multiplier Override, Wait Bluetooth Interval, Light Sleep Interval and Minimum Wake Interval.
Security The security config options are: Public Key, Private Key, Admin Key, Is Managed, Serial Console, Debug Logs, and Admin Channel.
User The user config options are: Long Name, Short Name, and Is Licensed.
