Meshtastic Hardware
Meshtastic
Meshtastic is an open-source, decentralized communication system that uses LoRa (Long Range) radio technology to enable off-grid messaging without relying on cellular networks or the internet. It is designed for outdoor enthusiasts, emergency responders, and anyone needing reliable communication in remote areas.
Feature | Description |
---|---|
Long-Range Communication | Supports distances up to 331 km in optimal conditions. |
Mesh Networking | Devices relay messages to extend coverage, ensuring connectivity even in difficult terrain. |
Low Power Consumption | LoRa technology allows devices to operate for extended periods on battery power. |
Encrypted Messaging | Secure communication using AES-256 encryption. |
GPS Integration | Supports location sharing for navigation and tracking. |
No Dedicated Router Needed | Works without centralized infrastructure, making it ideal for disaster scenarios. |
Bluetooth Connectivity | Allows easy pairing with smartphones for configuration and messaging. |
Multi-Channel Support | Users can create multiple encrypted channels for different groups. |
Open-Source & Community-Driven | Constantly evolving with contributions from developers worldwide. |


La LILYGO T-Deck Plus è una scheda di sviluppo versatile progettata per progetti IoT e embedded. Dotata di un potente chip ESP32, offre opzioni di connettività robuste, tra cui Wi-Fi e Bluetooth. Con un display touch screen integrato, fornisce un interfaccia intuitiva per l'interazione con l'utente. La T-Deck Plus è equipaggiata con vari pin di input/output, rendendo facile collegare sensori e moduli. Ideale sia per hobbisti che per professionisti, questa scheda supporta molteplici ambienti di programmazione, permettendo uno sviluppo rapido e il prototipaggio di applicazioni intelligenti. Sia per automazione domestica, robotica o tecnologia indossabile, la LILYGO T-Deck Plus è una scelta affidabile per progetti innovativi.

È un tracker ad alte prestazioni progettato per Meshtastic, piccolo come una carta di credito, che si adatta facilmente alla tua tasca o si può attaccare ai tuoi beni. Integra il LR1110 di Semtech (supporta la gamma 863-928 MHz), il nRF52840 di Nordic e il modulo GPS AG3335 di Mediatek, offrendo agli utenti Meshtastic una posizione ad alta precisione, una soluzione di comunicazione e posizionamento a basso consumo.

Vision Master T190 (HT-VMT190) è un kit di sviluppo con ESP32-S3 e Modulo LoRa (opzionale). Il display TFT-LCD da 1,9 pollici integrato contiene 170 (RGB) x 320 punti e può visualizzare fino a 262k colori. Lavorando con i programmi di esempio e gli strumenti di sviluppo che forniamo, gli utenti possono operare il display tramite Bluetooth, Wi-Fi e LoRa. Supporta anche la programmazione quotidiana di livello base e esegue progetti open source come Meshtastic.
Domande frequenti su Meshtastic
A cosa serve Meshtastic?
Meshtastic è legale?
Meshtastic è gratuito?
Qual è la differenza tra walkie talkie e Meshtastic?
Meshtastic Region Codes
Region Code | Description | Frequency Range (MHz) | Duty Cycle (%) | Power Limit (dBm) |
---|---|---|---|---|
UNSET | Unset | N/A | N/A | N/A |
US | United States | 902.0 - 928.0 | 100 | 30 |
EU_433 | European Union 433MHz | 433.0 - 434.0 | 10 | 12 |
EU_868 | European Union 868MHz | 869.4 - 869.65 | 10 | 27 |
CN | China | 470.0 - 510.0 | 100 | 19 |
JP | Japan | 920.8 - 927.8 | 100 | 16 |
ANZ | Australia & New Zealand | 915.0 - 928.0 | 100 | 30 |
KR | Korea | 920.0 - 923.0 | N/A | N/A |
TW | Taiwan | 920.0 - 925.0 | 100 | 27 |
RU | Russia | 868.7 - 869.2 | 100 | 20 |
IN | India | 865.0 - 867.0 | 100 | 30 |
NZ_865 | New Zealand 865MHz | 864.0 - 868.0 | 100 | 36 |
TH | Thailand | 920.0 - 925.0 | 100 | 16 |
UA_433 | Ukraine 433MHz | 433.0 - 434.7 | 10 | 10 |
UA_868 | Ukraine 868MHz | 868.0 - 868.6 | 1 | 14 |
MY_433 | Malaysia 433MHz | 433.0 - 435.0 | 100 | 20 |
MY_919 | Malaysia 919MHz | 919.0 - 924.0 | 100 | 27 |
SG_923 | Singapore 923MHz | 917.0 - 925.0 | 100 | 20 |
LORA_24 | 2.4 GHz band worldwide | 2400.0 - 2483.5 | 100 | 10 |
Meshtastic Radio Configuration
Name | Description |
---|---|
Bluetooth | The bluetooth config options are: Enabled, Pairing Mode and Fixed PIN. |
Channels | The channels config options are: Index, Role and Settings. |
Device | The device config options are: Device Role, Serial Output, Debug Log and Factory Reset. |
Display | The display config options are: Screen On Duration, Auto Carousel Interval, Always Point North, and GPS Format. |
LoRa | The LoRa config options are: Region, Modem Preset, Max Hops, Transmit Power, Bandwidth, Spread Factor, Coding Rate, Frequency Offset, Transmit Disabled and Ignore Incoming Array. |
Network | The network config options are: WiFi Enabled, WiFi SSID, WiFi PSK, WiFi Mode and NTP Server. |
Position | The position config options are: GPS Enabled, GPS Update Interval, GPS Attempt Time, Fixed Position, Smart Broadcast, Broadcast Interval and Position Packet Flags. |
Power | The power config options are: Charge Current, Power Saving, Shutdown after losing power, ADC Multiplier Override, Wait Bluetooth Interval, Light Sleep Interval and Minimum Wake Interval. |
Security | The security config options are: Public Key, Private Key, Admin Key, Is Managed, Serial Console, Debug Logs, and Admin Channel. |
User | The user config options are: Long Name, Short Name, and Is Licensed. |
