Upgraded based on T-Deck, mainly added GPS module and Built-in 2000 mah battery.
An external antenna connector is reserved on the case, you can connect it by opening the small hole in the case.
【Keyboard letter styles are sent randomly】
Product Information
sample code and more detailed information
Specifications
| MCU | ESP32-S3FN16R8 Dual-core LX7 microprocessor |
| Wireless Connectivity | 2.4 GHz Wi-Fi & Bluetooth 5 (LE) |
| Development | Arduino, PlatformlO-IDE, Micropython |
| Flash | 16MB |
| PSRAM | 8MB |
| Battery ADC PIN | IO04 |
| Onboard functions | GPS, TF Card, Microphone, Speaker |
|
2.8 inch ST7789 SPI Interface IPS LCD: Resolution: 320 x 240 Full viewing angle |
| SX1262 LoRa Transceiver |
| Transmit power | +22dBm |
| Frequency Optional | 433/868/915Mhz |
Product Size
Pin Diagram
