What is the Difference between LILYGO T-Embed and T-Embed CC1101
LILYGO is a well-known brand in the embedded development board market, offering powerful solutions for a wide range of applications. Among its popular products are the LILYGO T-Embed and LILYGO T-Embed CC1101, both of which provide versatile features tailored to different IoT development needs. In this article, we will compare these two models, highlighting their key differences and suitable applications to help you decide which one is right for your project.
What is LilyGO T-embed?
The LILYGO T-Embed is a compact, multifunctional embedded development board designed for a wide variety of IoT applications. It integrates an ESP32-S3 microcontroller, which brings the power of Wi-Fi and Bluetooth 5 connectivity to your projects. This makes it perfect for applications ranging from smart home systems to wearables.
LILYGO T-Embed
What are the advantages of LILYGO T-Embed?
- Microcontroller: Powered by the ESP32-S3, a dual-core processor that supports Wi-Fi (802.11 b/g/n) and Bluetooth 5.
- Display: Features a 1.9-inch IPS color TFT LCD (170x320 resolution) for clear user interaction.
- Wireless Communication: Supports Wi-Fi and Bluetooth 5, ideal for general-purpose IoT applications.
- User Interface: Includes a rotary encoder, buttons, microphone, and speaker for diverse I/O interaction.
- Input/Output Options: Equipped with a variety of GPIO pins, making it flexible for custom projects.
- Battery Protection: Offers battery charge and discharge protection via a 1.25mm battery interface.
This board is ideal for creating smart devices, wearable tech, or any other IoT system requiring both Bluetooth and Wi-Fi connectivity
What is LilyGO T-embed CC1101?
The LILYGO T-Embed CC1101 builds upon the T-Embed’s solid foundation but introduces Sub-GHz communication capabilities for long-range, low-power wireless communication. It integrates a CC1101 transceiver and an antenna, supporting multiple frequency bands (300-348 MHz, 387-464 MHz, and 779-928 MHz), making it an ideal choice for applications requiring long-range communication like IoT sensor networks and remote control systems.
LILYGO T-Embed CC1101
What are the advantages of LILYGO T-Embed CC1101？
- Microcontroller: Also powered by the ESP32-S3, providing dual-core processing and support for Wi-Fi and Bluetooth.
- Wireless Communication: Features Sub-GHz communication with CC1101 for long-range (up to 50 meters) low-power IoT solutions.
- NFC/RFID Support: Built-in PN532 NFC/RFID module that supports 125/134KHz and 13.56MHz frequencies for IoT applications involving RFID or NFC.
- Display: Same 1.9-inch IPS color TFT LCD as the T-Embed, with 170x320 resolution.
- Additional Features: Includes a rotary encoder, speaker, and GPIO pins, along with an IR transmitter/receiver and a battery voltage detection function.
This board is tailored for use in low-power IoT sensor networks and remote control applications, where longer communication ranges and minimal power consumption are essential.
Comparison of LILYGO T-Embed and T-Embed CC1101
|
Feature |
LILYGO T-Embed |
LILYGO T-Embed CC1101 |
|
MCU (Microcontroller) |
ESP32-S3 Dual-core LX7 |
|
|
Display |
1.9-inch IPS TFT LCD (170x320) |
1.9-inch IPS TFT LCD (170x320) |
|
Wireless Communication |
Wi-Fi (802.11 b/g/n), Bluetooth 5 |
Wi-Fi, Bluetooth 5, Sub-GHz (CC1101) |
|
NFC/RFID Support |
N/A |
PN532 NFC/RFID module (125/134KHz and 13.56MHz) |
|
Maximum Range |
Limited by Wi-Fi and Bluetooth range |
Up to 50 meters with Sub-GHz communication |
|
Input/Output |
GPIO pins, rotary encoder, buttons |
GPIO pins, rotary encoder, buttons, SPI |
|
Battery Support |
Battery charge and discharge protection |
Battery voltage detection, charge/discharge protection |
|
Interface |
USB Type-C, TF card holder, 2.54 x 8pin GPIO |
|
|
Audio |
Speaker (8Ω, 1W) |
Speaker (8Ω, 1W), IR Transmit & Receive |
|
Programming Platform |
||
|
Applications |
General-purpose IoT, smart homes, wearables |
IoT, sensor networks, remote control, long-range communication |
Which product is right for you?
Both the LILYGO T-Embed and the LILYGO T-Embed CC1101 are excellent choices for embedded development, with each serving different project needs. The LILYGO T-Embed is perfect for general-purpose IoT applications requiring Wi-Fi and Bluetooth connectivity. If your project demands long-range, low-power wireless communication, the LILYGO T-Embed CC1101 is the ideal choice, especially with its integrated CC1101 Sub-GHz transceiver and NFC/RFID functionality.When choosing between these two, consider the specific needs of your application. If you need longer communication range and lower power consumption, the T-Embed CC1101 will provide you with the best performance. On the other hand, for general-purpose IoT applications, the T-Embed offers a more versatile and feature-rich solution.
FAQs
What is LilyGO？
LILYGO is a technology company dedicated to the development of IoT, offering open-source hardware products, IoT modules, and STEM education kits. They integrate R&D, production, and sales, focusing on innovation and customization to make development easier and support creative projects worldwide.
What is LilyGO T-embed?
T-Embed is an Internet of Things (IoT) embedded panel specifically designed for programmable development. The product is characterized by a black shell and black keys. It is constructed from ABS and PC materials, with an optional translucent variant available. The design encompasses a standardized integration of the panel and circuit board, ensuring compatibility and ease of use in various applications.
