Meshtastic Hardware
Meshtastic
Meshtastic is an open-source, decentralized communication system that uses LoRa (Long Range) radio technology to enable off-grid messaging without relying on cellular networks or the internet. It is designed for outdoor enthusiasts, emergency responders, and anyone needing reliable communication in remote areas.
Feature | Description |
---|---|
Long-Range Communication | Supports distances up to 331 km in optimal conditions. |
Mesh Networking | Devices relay messages to extend coverage, ensuring connectivity even in difficult terrain. |
Low Power Consumption | LoRa technology allows devices to operate for extended periods on battery power. |
Encrypted Messaging | Secure communication using AES-256 encryption. |
GPS Integration | Supports location sharing for navigation and tracking. |
No Dedicated Router Needed | Works without centralized infrastructure, making it ideal for disaster scenarios. |
Bluetooth Connectivity | Allows easy pairing with smartphones for configuration and messaging. |
Multi-Channel Support | Users can create multiple encrypted channels for different groups. |
Open-Source & Community-Driven | Constantly evolving with contributions from developers worldwide. |


De LILYGO T-Deck Plus is een veelzijdige ontwikkelbord ontworpen voor IoT en embedded projecten. Met een krachtige ESP32-chip biedt het robuuste connectiviteitsopties, waaronder Wi-Fi en Bluetooth. Met een geïntegreerd touchscreen display biedt het een intuïtieve interface voor gebruikersinteractie. De T-Deck Plus is uitgerust met verschillende input/output-pinnen, waardoor het gemakkelijk is om sensoren en modules aan te sluiten. Ideaal voor hobbyisten en professionals eveneens, ondersteunt dit bord meerdere programmeermilieus, wat snelle ontwikkeling en prototyping van slimme toepassingen mogelijk maakt. Of het nu gaat om huisautomatisering, robotica of wearable technologie, de LILYGO T-Deck Plus is een betrouwbare keuze voor innovatieve projecten.

Het is een hoogwaardige tracker ontworpen voor Meshtastic, zo klein als een creditcard, die moeiteloos in je zak past of aan je bezittingen kan worden bevestigd. Het bevat Semtech's LR1110 (ondersteunt het 863-928 MHz bereik), Nordic's nRF52840, en Mediatek's AG3335 GPS-module, en biedt Meshtastic-gebruikers een hoogwaardige precisie, laag energieverbruik positionering en communicatieoplossing.

Vision Master T190 (HT-VMT190) is een ontwikkelkit met ESP32-S3 en een LoRa-module (optioneel). Het ingebouwde 1,9-inch TFT-LCD-scherm bevat 170 (RGB) x 320 pixels en kan tot 262k kleuren weergeven. Met de voorbeeldprogramma's en ontwikkeltools die wij bieden, kunnen gebruikers het scherm bedienen via Bluetooth, Wi-Fi en LoRa. Het ondersteunt ook dagelijks instapniveau programmeren en draait open source projecten zoals Meshtastic.
Meshtastic FAQ
Waar wordt Meshtastic voor gebruikt?
Is Meshtastic legaal?
Is Meshtastic gratis?
Wat is het verschil tussen walkietalkies en Meshtastic?
Meshtastic Region Codes
Region Code | Description | Frequency Range (MHz) | Duty Cycle (%) | Power Limit (dBm) |
---|---|---|---|---|
UNSET | Unset | N/A | N/A | N/A |
US | United States | 902.0 - 928.0 | 100 | 30 |
EU_433 | European Union 433MHz | 433.0 - 434.0 | 10 | 12 |
EU_868 | European Union 868MHz | 869.4 - 869.65 | 10 | 27 |
CN | China | 470.0 - 510.0 | 100 | 19 |
JP | Japan | 920.8 - 927.8 | 100 | 16 |
ANZ | Australia & New Zealand | 915.0 - 928.0 | 100 | 30 |
KR | Korea | 920.0 - 923.0 | N/A | N/A |
TW | Taiwan | 920.0 - 925.0 | 100 | 27 |
RU | Russia | 868.7 - 869.2 | 100 | 20 |
IN | India | 865.0 - 867.0 | 100 | 30 |
NZ_865 | New Zealand 865MHz | 864.0 - 868.0 | 100 | 36 |
TH | Thailand | 920.0 - 925.0 | 100 | 16 |
UA_433 | Ukraine 433MHz | 433.0 - 434.7 | 10 | 10 |
UA_868 | Ukraine 868MHz | 868.0 - 868.6 | 1 | 14 |
MY_433 | Malaysia 433MHz | 433.0 - 435.0 | 100 | 20 |
MY_919 | Malaysia 919MHz | 919.0 - 924.0 | 100 | 27 |
SG_923 | Singapore 923MHz | 917.0 - 925.0 | 100 | 20 |
LORA_24 | 2.4 GHz band worldwide | 2400.0 - 2483.5 | 100 | 10 |
Meshtastic Radio Configuration
Name | Description |
---|---|
Bluetooth | The bluetooth config options are: Enabled, Pairing Mode and Fixed PIN. |
Channels | The channels config options are: Index, Role and Settings. |
Device | The device config options are: Device Role, Serial Output, Debug Log and Factory Reset. |
Display | The display config options are: Screen On Duration, Auto Carousel Interval, Always Point North, and GPS Format. |
LoRa | The LoRa config options are: Region, Modem Preset, Max Hops, Transmit Power, Bandwidth, Spread Factor, Coding Rate, Frequency Offset, Transmit Disabled and Ignore Incoming Array. |
Network | The network config options are: WiFi Enabled, WiFi SSID, WiFi PSK, WiFi Mode and NTP Server. |
Position | The position config options are: GPS Enabled, GPS Update Interval, GPS Attempt Time, Fixed Position, Smart Broadcast, Broadcast Interval and Position Packet Flags. |
Power | The power config options are: Charge Current, Power Saving, Shutdown after losing power, ADC Multiplier Override, Wait Bluetooth Interval, Light Sleep Interval and Minimum Wake Interval. |
Security | The security config options are: Public Key, Private Key, Admin Key, Is Managed, Serial Console, Debug Logs, and Admin Channel. |
User | The user config options are: Long Name, Short Name, and Is Licensed. |
