E Ink Display's Basic Function
- Refresh method: Full update for 4s、Partial update for 0.4s (tested at 25°C ambient temperature)
- Display orientation: Horizontal or vertical
E Ink Display's Basic Parameters
- Product size: 10.85 inch
- Resolution: 1360x480
- PPI: 132.92
- Color: Black and White
- Driver IC: JD79686AB
- Interface: SPI
- Operating voltage: 3.3V
- Operating temperature: 0-50 ℃
E Ink Display's Main Features
- Display feature: Bistable display (retains the current content after a power outage)
- Display mode: Pure reflection
- Viewing angle: Wide viewing angle exceeding 170 degrees
- Surface Treatment: Hard-coated for anti-glare effects
- Energy conservation: No power consumption when not refreshing the screen
- Eye Protection: No blue light emission, zero radiation
PARAMETERS
| PART NUMBER | GDEM1085T51 |
| SIZE | 10.85 inch |
| TYPE | Dot Matrix |
| IC | JD79686AB |
| RESOLUTION | 1360x480 |
| PPI | 132.92 |
| OUTLINE SIZE(mm) | 270.56×105.92 ×1.20 |
| ACTIVE SIZE(mm) | 259.76×91.68 |
| PIXEL PITCH(mm) | 0.191x0.191 |
| OPERATING TEMP. | 0℃~50℃ |
| STORAGE TEMP. | -25℃~70℃ |
| CONNECTOR | 24 Pin FPC |
| MAX GRAYSCALE | 2 |
| COLOR | Black, White |
| INTERFACE | SPI |
| FULL UPDATE TIME(s) | 4 |
| PARTIAL UPDATE TIME(s) | 0.4 |
| TYPICAL POWER(mW) | 45 |
| DEEP SLEEP POWER(mW) | 0.006 |
