The T5-4.7-S3 Epaper PRO is a highly integrated, ultra-low-power development board designed for IoT applications requiring long-range communication and dynamic visual display. Combining a 4.7-inch E-Paper screen (960×540, 16 grayscale), an ESP32-S3-WROOM-1 MCU (16MB Flash + 8MB PSRAM), and an SX1262 LoRa transceiver (supporting 433/868/915 MHz), this board enables energy-efficient data transmission and visualization with support for Wi-Fi 2.4GHz/BLE 5, capacitive touch, RTC, TF storage, and optional GPS. Its advanced power management system (BQ25896/BQ27220) and magnetic wireless charging support ensure extended operation, making it ideal for smart signage, environmental monitoring, asset tracking, and other battery-powered IoT projects.
Key Technologies
- 📟 ESP32-S3 Dual-Core MCU
-
-
Processor: Xtensa® 32-bit LX7 dual-core CPU (up to 240 MHz)
-
Memory: 16MB Flash + 8MB PSRAM for complex applications
-
Connectivity: 2.4 GHz Wi-Fi & Bluetooth 5 (BLE)
-
- 📡 LoRa Wireless Communication (SX1262)
-
-
Frequency Bands: Supports 433MHz, 868MHz, 915MHz (regional compliance)
-
Long-Range: Up to 5km (line-of-sight) with low power consumption
-
Antenna Options: Onboard PCB antenna or external antenna connector
-
- 🖥️ 4.7-inch E-Paper Display
-
-
Driver IC: ED047TC1
-
Resolution: 960×540 pixels
-
Gray Levels: 16-level grayscale
-
Ultra-Low Power: Only consumes power during refresh (zero power when static)
-
- 🔋 Advanced Power Management
-
-
Charging IC: BQ25896 (supports wireless charging)
-
Fuel Gauge: BQ27220 for accurate battery monitoring
-
RTC (PCF8563): Real-time clock with timestamping capabilities
-
- 🛠️ Rich Expansion Interfaces
-
-
Touch Control: Capacitive touch (2-point support)
-
Storage: MicroTF card slot
-
Sensors: Built-in accelerometer (2.5D arc design)
-
GPIO Breakout: 14+ extended GPIOs for sensors/peripherals
-
Key Parameters
| Category | Specification |
|---|---|
| MCU | ESP32-S3 (16MB Flash + 8MB PSRAM) |
| Wireless | Wi-Fi 2.4GHz + BLE 5 + LoRa (SX1262) |
| Display | 4.7" E-Paper (960×540, 16 grayscale) |
| Touch | Capacitive touch (2-point) |
| Power Management | BQ25896 + BQ27220 + wireless charging support |
| Expansion | TF card, RTC, accelerometer, GPIOs |
Applications
-
🏷️ IoT Information Displays: Smart price tags, inventory management
-
🌡️ Environmental Monitoring Stations: Temperature/humidity data with LoRa transmission
-
📍 Asset Tracking: GPS + LoRa for real-time location logging
-
🔋 Low-Power Sensor Nodes: Battery-operated devices requiring months of autonomy
Competitive Advantages
-
🎯 All-in-One Design: Integrates display, wireless, and sensing in a compact form factor
-
⚡ Ultra-Low Power: E-Paper + LoRa + ESP32-S3 sleep modes enable year-long battery life
-
🔧 Developer-Friendly: Supports Arduino IDE & VS Code; full pinouts exposed for customization
